| Voltage | 380VAC/220VAC |
| Max Static Load | ER2D:3000KG ER3D:3800KG |
| Suspection | 2:1 |
| Control Method | VVVF |
| Brake | DC110V, 1.2A |
| Weight | ER2D:355kg ER3D:420kg |
| Model | Load(kg) | Lift speed m/s | Height | Sheave Diam (mm) | Rope Sheave (mm) | Motor Power (KW) | IP Grade |
|---|---|---|---|---|---|---|---|
| ER2D | 800 | 1 | ≤80 | Φ320 | 6xΦ8x12 | 5.6 | IP41 |
| ER2D | 800 | 1.5 | ≤80 | Φ320 | 6xΦ8x12 | 8.4 | IP41 |
| ER2D | 800 | 1.6 | ≤80 | Φ320 | 6xΦ8x12 | 9 | IP41 |
| ER2D | 800 | 1.75 | ≤80 | Φ320 | 6xΦ8x12 | 9.8 | IP41 |
| ER2D | 800 | 2 | ≤80 | Φ320 | 6xΦ8x12 | 11.3 | IP41 |
| ER2D | 1000 | 1 | ≤80 | Φ320 | 7xΦ8x12 | 6.9 | IP41 |
| ER2D | 1000 | 1.6 | ≤80 | Φ320 | 7xΦ8x12 | 10.3 | IP41 |
| ER2D | 1000 | 1.75 | ≤80 | Φ320 | 7xΦ8x12 | 11 | IP41 |
| ER2D | 1000 | 1 | ≤80 | Φ320 | 7xΦ8x12 | 12 | IP41 |
| ER2D | 1000 | 1.5 | ≤80 | Φ320 | 7xΦ8x12 | 13.8 | IP41 |
| ER3D | 1150 | 1.6 | ≤80 | Φ320 | 8xΦ8x12 | 7.7 | IP41 |
| ER3D | 1150 | 1.75 | ≤80 | Φ320 | 8xΦ8x12 | 11.8 | IP41 |
| ER3D | 1150 | 1.5 | ≤80 | Φ320 | 8xΦ8x12 | 12.7 | IP41 |
| ER3D | 1150 | 1.6 | ≤80 | Φ320 | 8xΦ8x12 | 13.8 | IP41 |
| ER3D | 1250 | 1.75 | ≤80 | Φ320 | 8xΦ8x12 | 8.5 | IP41 |
| ER3D | 1250 | 1.5 | ≤80 | Φ320 | 8xΦ8x12 | 12.7 | IP41 |
| ER3D | 1250 | 1.6 | ≤80 | Φ320 | 8xΦ8x12 | 13.8 | IP41 |
| ER3D | 1250 | 1.75 | ≤80 | Φ320 | 8xΦ8x12 | 14.9 | IP41 |
