| Max Static Load | 7500kg |
| Suspection | 1:1 |
| Control Method | VVVF |
| Brake | DC110V, 2A |
| Weight | 285kg(with support) |
| As shown is right sheave type,left sheave type is optional . | |
| Load(kg) | Lift speed m/s | Radio | Sheave Diam (mm) | Rope Sheave (mm) | Motor Power (KW) | Pole |
|---|---|---|---|---|---|---|
| 800 | 1.6 | 59:2 | Φ620 | 5xΦ13x20 | 12.5 | 4 |
| 800 | 1.75 | 55:3 | Φ620 | 5xΦ13x20 | 15 | 4 |
| 800 | 2 | 49:2 | Φ620 | 6xΦ13x20 | 18.5 | 4 |
| 1000 | 1 | 49:1 | Φ620 | 5xΦ13x20 | 11 | 4 |
| 1000 | 1.6 | 59:2 | Φ620 | 6xΦ13x20 | 18.5 | 4 |
| 1000 | 1.75 | 55:2 | Φ620 | 6xΦ13x20 | 18.5 | 4 |
| 1000 | 2 | 49:2 | Φ620 | 6xΦ13x20 | 18.5 | 4 |
| 1150 | 1 | 49:1 | Φ620 | 6xΦ13x20 | 15 | 4 |
| 1150 | 1.6 | 59:2 | Φ620 | 6xΦ13x20 | 18.5 | 4 |
| 1150 | 1.75 | 55:2 | Φ620 | 6xΦ13x20 | 18.5 | 4 |
| 1150 | 2 | 49:2 | Φ620 | 6xΦ13x20 | 22 | 4 |
