ESNB02-03 TVVBP TVVBPG Elevator Flat PVC Control Cable

Type	Conductor Section(mm²)	Conductor Construction(mm²)	Product Dia.(mm)	70℃Insulated Resister(MΩ·KM)	20℃Conductor DC Resister(Ω/KM)
TVVBP	36X0.75+(2X2P)X0.75	30/0.18	62.0X9.8	≥0.011	≤26.0
TVVBP	36X0.75+(2X2P)X0.75+TV(STV75-4)	30/0.18	61.5X9.0	≥0.011	≤26.0
TVVBP	40X0.75+(2X2P)X0.75	30/0.18	61.5X9.0	≥0.011	≤26.0
TVVBP	48X0.75+(2X2P)X0.75	30/0.18	68.5X10.0	≥0.011	≤26.0
TVVBP	30X0.75+(2X2P)X0.75	30/0.18	52.5X9.0	≥0.011	≤26.0
TVVBP	20X0.75+(2X2P)X0.75	30/0.18	44.2X9.1	≥0.011	≤26.0
TVVBP	24X0.75+(2X2P)X0.75	30/0.18	42.5X9.0	≥0.011	≤26.0
TVVBP	48X0.75+(2X2P)X0.75	30/0.18	68.5X9.5	≥0.011	≤26.0
TVVBPG	36X0.75+(2X2P)X0.75	30/0.18	63.0X9.2	≥0.011	≤26.0
TVVBPG	36X0.75+(2X2P)X0.75+TV(SYV75-4)	30/0.18	72.5X9.9	≥0.011	≤26.0
TVVBPG	42X0.75+(2X2P)X0.75	30/0.18	75.0X9.8	≥0.011	≤26.0
TVVBPG	48X0.75+(2X2P)X0.75	30/0.18	80.0X9.5	≥0.011	≤26.0
TVVBPG	20X0.75+(2X2P)X0.75	30/0.18	51.0X8.9	≥0.011	≤26.0
TVVBPG	24X0.75+(2X2P)X0.75	30/0.18	64.0X10.2	≥0.011	≤26.0
TVVBPG	30X0.75+(2X2P)X0.75	30/0.18	58.0X8.2	≥0.011	≤26.0
TVVBPG	40X0.75+(2X2P)X0.75	30/0.18	74.0X9.0	≥0.011	≤26.0
