ESNB02-02 TVVB TVVBG Elevator Flat PVC Control Cable

Type	Conductor Section(mm²)	Conductor Construction(mm²)	Product Dia.(mm)	70℃Insulated Resister(MΩ·KM)	20℃Conductor DC Resister(Ω/KM)
TVVB	8X0.75	30/0.18	22.2X4.5	≥0.011	≤26.0
TVVB	20X0.75	30/0.18	29.9X9.0	≥0.011	≤26.0
TVVB	24X0.75	30/0.18	30.5X9.1	≥0.011	≤26.0
TVVB	28X0.75+4X2	30/0.18+37/0.26	46.0X10.0	≥0.011/0.010	≤26.0/10.2
TVVB	20X0.75+(2X2)X0.75	30/0.18	44.2X9.1	≥0.011	≤26.0
TVVB	36X0.75+(2X2)X0.75	30/0.18	62X10.0	≥0.011	≤26.0
TVVB	48X0.75+(2X2)X0.75	30/0.18	68.5X10.0	≥0.011	≤26.0
TVVB	30X0.75	30/0.18	44.2X9.1	≥0.011	≤26.0
TVVB	36X0.75	30/0.18	42.5X9.0	≥0.011	≤26.0
TVVB	40X0.75	30/0.18	52.5X9.0	≥0.011	≤26.0
TVVB	42X0.75	30/0.18	54.1X9.7	≥0.011	≤26.0
TVVB	48X0.75	30/0.18	58.0X9.6	≥0.011	≤26.0
TVVBG	2X1.0+TV(SYV75-4)	7/0.24+50/0.16	15.8X7.6	≥0.010	≤19.5
TVVBG	20X0.75+4X2	30/0.18+37/0.26	50.3X9.7	≥0.011/0.010	≤26.0/10.2
TVVBG	28X0.75+4X2	30/0.18+37/0.26	54.0X9.5	≥0.011/0.010	≤26.0/10.2
TVVBG	30X0.75	30/0.18	53X8.6	≥0.011	≤26.0
TVVBG	36X0.75	30/0.18	54.0X9.5	≥0.011	≤26.0
TVVBG	40X0.75	30/0.18	58X8.2	≥0.011	≤26.0
TVVBG	42X0.75	30/0.18	66.6X9.7	≥0.011	≤26.0
TVVBG	48X0.75	30/0.18	67.2X9.5	≥0.011	≤26.0
