| Model | Number of Infra Red Diodes | Scanning Beams | Protection Height | Detecting range | Voltage |
|---|---|---|---|---|---|
| ESNF06-917A6 | 17 | 94-33Beams | 20-1841mm | 0-4m | AC220v/AC110V/DC24V |
| ESNF06-917A7 | 32 | 154-94Beams | 20-1841mm | 0-4m | AC220v/AC110V/DC24V |
| Model | Number of Infra Red Diodes | Scanning Beams | Protection Height | Detecting range | Voltage |
|---|---|---|---|---|---|
| ESNF06-957A6 | 17 | 94-33Beams | 20-1841mm | 0-4m | AC220v/AC110V/DC24V |
| ESNF06-957A7 | 32 | 154-94Beams | 20-1841mm | 0-4m | AC220v/AC110V/DC24V |
| ESNF06-957A8 | 40 | 194-118Beams | 20-1872mm | 0-4m | AC220v/AC110V/DC24V |
| ESNF06-957A9 | 48 | 234-142Beams | 20-1900mm | 0-4m | AC220v/AC110V/DC24V |
| Model | Number of Infra Red Diodes | Scanning Beams | Protection Height | Detecting range | Voltage |
|---|---|---|---|---|---|
| ESNF06-987A5 | 36 | 174-106Beams | ≤20mm | 0-4m | AC220v/AC110V/DC24V |
| ESNF06-987A8 | 40 | 194-118Beams | ≤20mm | 0-4m | AC220v/AC110V/DC24V |
